Assigning Classification Rules to Policy Profiles
Parameters
profile-index
classify-index
vlan
cos
classify‐value
forward
drop
ether
llc
iptos
ipproto
ipsource
ipdest
udpportsource
udpportdest
tcpportsource
tcpportdest
macsource
macdest
ipfrag
port
class‐data‐val
class‐data‐mask
Defaults
If mask is not specified, all data bits will be considered relevant.
Mode
Switch command, Read‐Write.
Usage
Classification rules are automatically enabled when created.
8-12 Policy Classification Configuration
Specifies that this is an administrative rule or associates this
classification rule with a policy profile index configured with the set
policy profile command ("set policy profile" on page 8‐3). Valid profile‐
index values are 1‐ 63.
Policy Classification Index (1‐65535)
Specifies Vlan Classification Rule
Specifies Class Of Service Classification Rule
vlan / Class Of Service (0‐4095)
Specifies Forwarding of packet
Specifies Dropping of packet
Classifies based on type field in Ethernet II packet.
DSAP/SSAP pair in 802.3 type packet field ‐ (0 ‐ 65535)
Classifies based on Type of Service field in IP packet.
Classifies based on protocol field in IP packet.
Classifies based on source IP address
Classifies based on destination IP address
Classifies based on UDP port source ‐ supported class‐data‐val: 0 ‐
65535
Classifies based on UDP port destination ‐ supported class‐data‐val: 0 ‐
65535
Classifies based on TCP port source ‐ supported class‐data‐val: 0 ‐ 65535
Classifies based on TCP port destination ‐ supported class‐data‐val: 0 ‐
65535
Classifies based on MAC source address.
Classifies based on MAC destination address.
Classifies based on IP fragmentation value.
Classifies based on port‐string.
Data Value of meaning
Number of mask bits to apply to Data Value
set policy classify
