Setting Auto-Negotiation and Advertised Ability
10BASE-T
10BASE-TFD
100BASE-TX
100BASE-TXFD
1000BASE-X
1000BASE-XFD
1000BASE-T
1000BASE-TFD
other
pause
Apause
Spause
Bpause
Table 4‐3 provides an explanation of the command output.
Table 4-3 show port advertise Output Details
Output...
capability
advertised
remote

set port advertise

Use this command to enable or disable and to configure the advertised ability on one or more
ports.
Syntax
set port advertise port-string [10t] [10tfd] [100tx] [100txfd] [1000x] [1000xfd]
[1000t] [1000tfd] [pause] [apause] [spause] [bpause]
4-34 Port Configuration
yes yes
yes yes
yes yes
yes yes
no no
no no
no no
no no
no no
yes yes
no no
no no
no no
What it displays...
Whether or not the port is capable of operating in the following modes:
• 10t - 10BASE-T half duplex mode
• 10tfd - 10BASE-T full duplex mode
• 100tx - 100BASE-TX half duplex mode
• 100txfd - 100BASE-TX full duplex mode
• 1000x - 1000BASE-X, -LX, -SX, -CX half duplex mode
• 1000xfd - 1000BASE-X, -LX, -SX, -CX full duplex mode
• 1000t - 1000BASE-T half duplex mode
• 1000tfd - 1000BASE-T full duplex mode
• other - Other modes.
• pause - PAUSE for full-duplex links
• apause - Asymmetric PAUSE for full-duplex links
• spause - Symmetric PAUSE for full-duplex links
• bpause - Asymmetric and Symmetric PAUSE for full-duplex links
Whether or not the port is configured to advertise it is capable of
operating in the modes listed.
Whether this port's link partner is advertising the listed mode.
no
no
no
no
no
no
no
no
yes
no
no
no
no
set port advertise
