show vlan

3. Add the host port and the desired switch port to the egress list for the VLAN created in Step 1.
("set vlan egress" on page 7‐18)
4. Set a private community name and access policy. ("set snmp community" on page 5‐16)
The commands used to create a secure management VLAN are listed in Table
the associated sections as shown. This example assumes the management station is attached to
fe.1.1 and wants untagged frames.The process described in this section would be repeated on
every device that is connected in the network to ensure that each device has a secure management
VLAN.
Table 7-1 Command Set for Creating a Secure Management VLAN
To do this...
Create a new VLAN and confirm settings.
Set the PVIDs to the new VLAN.
Add the ports to the new VLAN's egress list.
Set a private community name and access
policy and confirm settings.

Reviewing Existing VLANs

Purpose

To display a list of VLANs currently configured on the device, to determine how one or more
VLANs were created, the ports allowed and disallowed to transmit traffic belonging to VLAN(s),
and if those ports will transmit the traffic with a VLAN tag included.

Command

For information about...
show vlan
show vlan
Use this command to display all information related to one or more VLANs.
Syntax
show vlan [static] [vlan-list]
Note: By default at device startup, there is one VLAN configured on the Matrix Series device. It is
VLAN ID 1, the DEFAULT VLAN. The default community name, which determines remote access
for SNMP management, is set to "public" with read-write access.
Use these commands...
set vlan create 2 ("set vlan" on page 7-6)
(Optional) show vlan 2 ("show
set port vlan host.0.1; fe.1.1 2
page 7-10)
set vlan egress 2 host.0.1; fe.1.1 2 untagged
egress" on page 7-18)
set snmp community private
page 5-16)
(Optional) show snmp community
community" on page 5-15)
Enterasys Matrix DFE-Gold Series Configuration Guide 7-3
Reviewing Existing VLANs
7‐1 and described in
vlan" on page 7-3)
("set port vlan" on
("set vlan
("set snmp community" on
("show snmp
Refer to page...
7-3
