Example
This example shows how to display the local system information stored for port ge.4.1. Table
describes the output fields of this command.
C2(rw)->show lldp port local-info ge.4.1
Local Port : ge.4.1
--------------------
Port Desc : ... 1000BASE-TX RJ45 Gigabit Ethernet Frontpanel Port
Mgmt Addr : 10.21.64.100
Chassis ID : 00-E0-63-93-74-A5
Sys Name : LLDP PoE test Chassis
Sys Desc : Enterasys Networks, Inc.
Sys Cap Supported/Enabled
Auto-Neg Supported/Enabled
Auto-Neg Advertised
Operational Speed/Duplex/Type : 100 full tx
Max Frame Size (bytes)
Vlan Id
LAG Supported/Enabled/Id
Protocol Id : Spanning Tree v-3 (IEEE802.1s)
LACP v-1
GVRP
PoE Device
PoE Power Source
PoE MDI Supported/Enabled
PoE Pair Controllable/Used
PoE Power Class
PoE Power Limit (mW)
PoE Power Priority
Table 4‐4 describes the information displayed by the show lldp port local‐info command.
Table 4-4 show lldp port local-info Output Details
Output Field
Local Port
Local Port Id
Port Desc
Mgmt Addr
Chassis ID
Sys Name
Sys Desc
Sys Cap Supported/Enabled
Local Port Id: ge.4.1
: bridge,router/bridge
: yes/yes
: 10BASE-T, 10BASE-TFD,
100BASE-TX, 100BASE-TXFD,
1000BASE-TFD,
Bpause
: 1522
: 1
: no/no/0
: PSE device
: primary
: yes/yes
: false/spare
: 2
: 15400
: high
What it Displays...
Identifies the port for which local system information is displayed.
Mandatory basic LLDP TLV that identifies the port transmitting the
LLDPDU. Value is ifName object defined in RFC 2863.
Optional basic LLDP TLV. Value is ifDescr object defined in RFC 2863.
Optional basic LLDP TLV. IPv4 address of host interface.
Mandatory basic LLDP TLV that identifies the chassis transmitting the
LLDPDU. Value is MAC address of chassis.
Optional basic LLDP TLV. Value is the administratively assigned name for
the system.
Optional basic LLDP TLV. Value is sysDescr object defined in RFC 3418.
Optional basic LLDP TLV. System capabilities, value can be bridge and/or
router.
show lldp port local-info
