Revision history
Date
03-Apr-2013
2042/2058
Table 1150. Revision history(Continued)
Rev
Table 818 ('Destructive' Event Status (RGM_DES) register Field
Descriptions): added field "F_SSCM_DEST"
Figure 3 ('Destructive' Event Reset Disable (RGM_DERD)
removed all registers except D_PORST and D_TSR_DEST
Table 819 ('Destructive' Event Reset Disable (RGM_DERD) register Field
Descriptions): added field "D_SSCM_DEST"
Figure 5 (Destructive' Bidirectional Reset Enable (RGM_DBRE)
– Updated register address information to "0x030" was (0x010)
– Added field "D_SSCM_DEST"
– Added field description for "BE_JTAG_DEST"
Figure 7 ('Functional' Event Reset Disable (RGM_FERD)
set to reserved (was ESR_0)
Table 15: 'Functional' Event Reset Disable (RGM_FERD) register field
descriptions: removed field "ESR_0"
Figure 8 ('Functional' Event Alternate Request Register
D_ESR0 bit set to reserved
Table 16: 'Functional' Event Alternate Request Register (RGM_FEAR) field
descriptions: removed field "D_ESR0"
Table 17: 'Functional' Bidirectional Reset Enable (RGM_FBRE) register
field descriptions: added description for field "BE_PLL0"
Figure 9 ('Functional' Bidirectional Reset Enable (RGM_FBRE)
changed reset value of field "BE_PLL0" from 17 to 1
Chapter 50, Boot Assist Flash (BAF)
2
Table 837 (BAF memory organization):
(cont'd)
– For "BAF data area and stack", new value "4000_0000h – 4000_01FFh"
added
– Changed Data and stack area 5280_0000h to 5280_01FFh
Section 50.3.2, Device initialization: bullet 4: added "SRAM area from
4000_0000h to 4000_03FFh" and changed BAF scratch memory
requirement to 512 bytes
Updated Figure 873 (Flow of control)
Section 50.3.4.1, 'Soft' DCF clients: added Serial Boot DCF client; added
paragraph "The serial boot DCF client provides...
Table 841 (BAF DCF client list): added Serial Boot DCF client address
Section 50.3.4.2.3, Security Watchdog Service Address (SEC_IAC8):
removed instance of "IOP" from Warning text
Added Section 50.3.4.6, BAF Serial Boot DCF Client --
SER_BOOT_CBACK
Added Table 844 (Serial boot callback function return value definition)
Updated Section 50.3.6, Optionally perform a serial boot
Updated Section 50.3.7, UART serial boot configuration
Section 50.4, Resources: removed "PFLASH" bulleted list item
Chapter 51, System Status and Configuration Module (SSCM)
Section 51.3.1.1, System Status Register (STATUS): changed bits 5 and 6
Section 51.4.1, DCF mechanism: removed paragraphs "The SSCM
maintains three DCF record areas..." and "Which of those areas are
scanned..."
