Hash processor (HASH)
35.4.2 HASH internal signals
Table 235
product level (on pads).
Signal name
hash_hclk
hash_it
hash_dma
35.4.3 About secure hash algorithms
The hash processor is a fully compliant implementation of the secure hash algorithm
defined by FIPS PUB 180-4 standard and the IETF RFC1321 publication (MD5).
With each algorithm, the HASH computes a condensed representation of a message or data
file. More specifically, when a message of any length below 2
HASH processing core produces respectively a fixed-length output string called a message
digest, defined as follows:
•
For MD5 digest size is 128-bit
•
For SHA-1 digest size is 160-bit
•
For SHA-224 and SHA-256, the digest size is 224 bits and 256 bits, respectively
The message digest can then be processed with a digital signature algorithm in order to
generate or verify the signature for the message.
Signing the message digest rather than the message often improves the efficiency of the
process because the message digest is usually much smaller in size than the message. The
verifier of a digital signature has to use the same hash algorithm as the one used by the
creator of the digital signature.
The SHA-2 functions supported by the hash processor are qualified as "secure" by NIST
because it is computationally infeasible to find a message that corresponds to a given
message digest, or to find two different messages that produce the same message digest
(SHA-1 does not qualify as secure since February 2017). Any change to a message in
transit will, with very high probability, result in a different message digest, and the signature
will fail to verify.
35.4.4 Message data feeding
The message (or data file) to be processed by the HASH should be considered as a bit
string. Per FIPS PUB 180-4 standard this message bit string grows from left to right, with
hexadecimal words expressed in "big-endian" convention, so that within each word, the
most significant bit is stored in the left-most bit position. For example message string "abc"
with a bit string representation of "01100001 01100010 01100011" is represented by a
32-bit word 0x00636261, and 8-bit words 0x61626300.
Data are entered into the HASH one 32-bit word at a time, by writing them into the
HASH_DIN register. The current contents of the HASH_DIN register are transferred to the
16 words input FIFO each time the register is written with new data. Hence HASH_DIN and
the FIFO form a seventeen 32-bit words length FIFO (named the IN buffer).
1146/2301
describes a list of useful to know internal signals available at HASH level, not at
Table 235. HASH internal input/output signals
Signal type
digital input
digital output
digital input/output DMA transfer request/ acknowledge
AHB bus clock
Hash processor global interrupt request
RM0432 Rev 6
Description
64
bits is provided on input, the
