AES hardware accelerator (AES)
34.7.3 AES data input register (AES_DINR)
Address offset: 0x08
Reset value: 0x0000 0000
Only 32-bit access type is supported.
31 30 29 28
rw rw rw rw
15 14 13 12
rw rw rw rw
Bits 31:0 DIN[31:0]: Input data word
A four-fold sequential write to this bitfield during the input phase results in writing a complete 128-bit
block of input data to the AES peripheral. From the first to the fourth write, the corresponding data
weights are [127:96], [95:64], [63:32], and [31:0]. Upon each write, the data from the 32-bit input
buffer are handled by the data swap block according to the DATATYPE[1:0] bitfield, then written into
the AES core 128-bit input buffer.
The data signification of the input data block depends on the AES operating mode:
- Mode 1 (encryption): plaintext
- Mode 2 (key derivation): the bitfield is not used (AES_KEYRx registers used for input)
- Mode 3 (decryption) and Mode 4 (key derivation then single decryption): ciphertext
The data swap operation is described in
page 1126.
34.7.4 AES data output register (AES_DOUTR)
Address offset: 0x0C
Reset value: 0x0000 0000
Only 32-bit read access type is supported.
31 30 29
r r r
15 14 13
r r r
