Bits 31:0 DOUT[31:0]: Output data word
This read-only bitfield fetches a 32-bit output buffer. A four-fold sequential read of this bitfield, upon
the computation completion (CCF set), virtually reads a complete 128-bit block of output data from
the AES peripheral. Before reaching the output buffer, the data produced by the AES core are
handled by the data swap block according to the DATATYPE[1:0] bitfield.
Data weights from the first to the fourth read operation are: [127:96], [95:64], [63:32], and [31:0].
The data signification of the output data block depends on the AES operating mode:
- Mode 1 (encryption): ciphertext
- Mode 2 (key derivation): the bitfield is not used (AES_KEYRx registers used for output)
- Mode 3 (decryption) and Mode 4 (key derivation then single decryption): plaintext
The data swap operation is described in
page 1126.
34.7.5 AES key register 0 (AES_KEYR0)
Address offset: 0x10
Reset value: 0x0000 0000
31 30 29
rw rw rw
15 14 13
rw rw rw
Bits 31:0 KEY[31:0]: Cryptographic key, bits [31:0]
This bitfield contains the bits [31:0] of the AES encryption or decryption key, depending on the
operating mode:
- In Mode 1 (encryption), Mode 2 (key derivation) and Mode 4 (key derivation then single
decryption): the value to write into the bitfield is the encryption key.
- In Mode 3 (decryption): the value to write into the bitfield is the encryption key to be derived before
being used for decryption. After writing the encryption key into the bitfield, its reading before
enabling AES returns the same value. Its reading after enabling AES and after the CCF flag is set
returns the decryption key derived from the encryption key.
Note: In mode 4 (key derivation then single decryption) the bitfield always contains the encryption
key.
The AES_KEYRx registers may be written only when KEYSIZE value is correct and when the AES
peripheral is disabled (EN bit of the AES_CR register cleared). Note that, if, the key is directly
loaded to AES_KEYRx registers (hence writes to key register is ignored and KEIF is set).
Refer to
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
Section 34.4.14: AES key registers on page 1128
Section 34.4.13: AES data registers and data swapping on
24 23 22
KEY[31:16]
rw rw rw
8 7 6
KEY[15:0]
rw rw rw
RM0432 Rev 6
AES hardware accelerator (AES)
21 20 19 18
rw rw rw rw
5 4 3 2
rw rw rw rw
for more details.
17 16
rw rw
1 0
rw rw
