3 Maintenance
3.5.1 Cleaning the IRB 1200
Continued
Protection
type
IP67 (option)
Foundry Plus
Clean room
Hygienic
i
ii
Wiping with cloth
Additional cleaning instructions for robots with food grade lubrication
Make sure that no liquid flows into the robot or stagnates in any gap or surface
after cleaning.
Cleaning with water and steam
Instructions for rinsing with water
IRB 1200 with protection class IP67 (option) and with protection type Foundry Plus
can be cleaned by rinsing with water (water cleaner).
The following list defines the prerequisites:
I
Instructions for steam or high pressure water cleaning
ABB robots with protection types Foundry Plus, Wash, or Foundry Prime can be
cleaned using a steam cleaner or high pressure water cleaner.
1
See Cleaning methods on page 149
2
See Cleaning methods on page 149
Continues on next page
150
Cleaning method
Vacuum Wipe with cloth
cleaner
Yes Yes. With light
cleaning deter-
gent.
Yes Yes. With light
cleaning deter-
gent or spirit.
Yes Yes. With light
cleaning deter-
gent, spirit or
isopropyl alco-
hol.
Yes Yes. Only with
detergent and
disinfectants re-
commended by
ABB.
Perform according to section
Perform according to section
• Maximum water pressure at the nozzle: 700 kN/m
• Fan jet nozzle should be used, min. 45° spread
• Minimum distance from nozzle to encapsulation: 0.4 meters
• Maximum flow: 20 liters/min
Typical tap water pressure and flow
for exceptions.
for exceptions.
© Copyright 2014 - 2021 ABB. All rights reserved.
Rinse with water
Yes. It is highly re-
commended that
the water contains
a rust-prevention
solution and that
the manipulator is
dried afterwards.
Yes. It is highly re-
commended that
the water contains
a rust-prevention
solution.
No
Yes. Only limited to
specific areas rather
than the complete
ii
robot.
Cleaning with water and steam on page
Cleaning the IRB 1200 with protection type Hygienic on page
I
High pressure water or
steam
No
i
Yes .
It is highly recommended
that the water and steam
contains rust preventive,
without cleaning deter-
gents.
No
Yes. Only limited to specif-
ic areas with assistance
of protective equipment.
150.
1
2 I
(7 bar)
2
Product manual - IRB 1200
3HAC046983-001 Revision: S
ii
152.
