RM0091
2
23.4.5 I C initialization
Enabling and disabling the peripheral
The I2C peripheral clock must be configured and enabled in the clock controller (refer to the
RCC Clocks section.
Then the I2C can be enabled by setting the PE bit in the I2Cx_CR1 register.
When the I2C is disabled (PE=0), the I2C performs a software reset: I2C lines (SDA and
SCL) are released. The internal state machines are reset, and all communication control
bits and status bits are put back to their reset value. The impacted bits are the same as
those listed in
Noise filters
Before you enable the I2C peripheral by setting the PE bit in I2Cx_CR1 register, you must
configure the noise filters, if needed. By default, an analog noise filter is present on the SDA
and SCL inputs. This analog filter is compliant with the I2C specification which requires the
suppression of spikes with a pulse width up to 50 ns in Fast Mode and Fast Mode Plus. You
can disable this analog filter by setting the ANFOFF bit, and/or select a digital filter by
configuring the DNF[3:0] bit in the I2Cx_CR1 register.
The digital filter is able to suppress spikes with a programmable length of 1 to 15 I2CCLK
periods.
Table 63.
Benefits
Drawbacks
Caution: Changing the filter configuration is not allowed when the I2C is enabled.
I2C timings
The timings must be configured in order to guarantee a correct data hold and setup time,
used in master and slave modes. This is done by programming the PRESC[3:0],
SCLDEL[3:0] and SDADEL[3:0] bits in the I2Cx_TIMINGR register.
Section 23.4.6: Software
Comparison of analog vs. digital filters
Analog filter
Available in Stop mode
Variation vs. temperature, voltage,
Doc ID 018940 Rev 1
Inter-integrated circuit (I
reset.
process
2
C) interface
Digital filter
1. Programmable length: extra
filtering capability vs. standard
requirements
2. Stable length
Disabled when Wakeup form Stop
mode is enabled
473/742
