General-purpose timers (TIM2 and TIM3)
16.4.8 TIM2 and TIM3 capture/compare mode register 2 (TIM2_CCMR2 and

TIM3_CCMR2)

Address offset: 0x1C
Reset value: 0x0000
Refer to the above CCMR1 register description.
15 14 13
OC4CE OC4M[2:0]
IC4F[3:0]
rw rw rw
Output compare mode
Bit 15 OC4CE: Output compare 4 clear enable
Bits 14:12 OC4M: Output compare 4 mode
Bit 11 OC4PE: Output compare 4 preload enable
Bit 10 OC4FE: Output compare 4 fast enable
Bits 9:8 CC4S: Capture/Compare 4 selection
Note: CC4S bits are writable only when the channel is OFF (CC4E = 0 in TIMx_CCER).
Bit 7 OC3CE: Output compare 3 clear enable
Bits 6:4 OC3M: Output compare 3 mode
Bit 3 OC3PE: Output compare 3 preload enable
Bit 2 OC3FE: Output compare 3 fast enable
Bits 1:0 CC3S: Capture/Compare 3 selection
Note: CC3S bits are writable only when the channel is OFF (CC3E = 0 in TIMx_CCER).
342/742
12 11 10 9
OC4PE OC4FE
CC4S[1:0]
IC4PSC[1:0]
rw rw rw rw
This bit-field defines the direction of the channel (input/output) as well as the used input.
00: CC4 channel is configured as output
01: CC4 channel is configured as input, IC4 is mapped on TI4
10: CC4 channel is configured as input, IC4 is mapped on TI3
11: CC4 channel is configured as input, IC4 is mapped on TRC. This mode is working only if
an internal trigger input is selected through TS bit (TIMx_SMCR register)
This bit-field defines the direction of the channel (input/output) as well as the used input.
00: CC3 channel is configured as output
01: CC3 channel is configured as input, IC3 is mapped on TI3
10: CC3 channel is configured as input, IC3 is mapped on TI4
11: CC3 channel is configured as input, IC3 is mapped on TRC. This mode is working only if
an internal trigger input is selected through TS bit (TIMx_SMCR register)
Doc ID 018940 Rev 1
8 7 6 5
OC3CE OC3M[2:0]
IC3F[3:0]
rw rw rw rw
4 3 2 1
OC3PE OC3FE
CC3S[1:0]
IC3PSC[1:0]
rw rw rw rw
