Advanced-control timers (TIM1)
Bits 2:0 SMS: Slave mode selection
When external signals are selected the active edge of the trigger signal (TRGI) is linked to
the polarity selected on the external input (see Input Control register and Control Register
description.
000: Slave mode disabled - if CEN = '1' then the prescaler is clocked directly by the internal
clock.
001: Encoder mode 1 - Counter counts up/down on TI2FP2 edge depending on TI1FP1
level.
010: Encoder mode 2 - Counter counts up/down on TI1FP1 edge depending on TI2FP2
level.
011: Encoder mode 3 - Counter counts up/down on both TI1FP1 and TI2FP2 edges
depending on the level of the other input.
100: Reset Mode - Rising edge of the selected trigger input (TRGI) reinitializes the counter
and generates an update of the registers.
101: Gated Mode - The counter clock is enabled when the trigger input (TRGI) is high. The
counter stops (but is not reset) as soon as the trigger becomes low. Both start and stop of
the counter are controlled.
110: Trigger Mode - The counter starts at a rising edge of the trigger TRGI (but it is not
reset). Only the start of the counter is controlled.
111: External Clock Mode 1 - Rising edges of the selected trigger (TRGI) clock the counter.
Note: The gated mode must not be used if TI1F_ED is selected as the trigger input
Table 44.
Slave TIM
TIM1
15.4.4

TIM1 DMA/interrupt enable register (TIM1_DIER)

Address offset: 0x0C
Reset value: 0x0000
15 14 13
Res. TDE COMDE CC4DE CC3DE CC2DE CC1DE
rw rw
Bit 15 Reserved, must be kept at reset value.
Bit 14 TDE: Trigger DMA request enable
0: Trigger DMA request disabled
1: Trigger DMA request enabled
Bit 13 COMDE: COM DMA request enable
0: COM DMA request disabled
1: COM DMA request enabled
Bit 12 CC4DE: Capture/Compare 4 DMA request enable
0: CC4 DMA request disabled
1: CC4 DMA request enabled
270/742
(TS='100'). Indeed, TI1F_ED outputs 1 pulse for each transition on TI1F, whereas the
gated mode checks the level of the trigger signal.
TIMx Internal trigger connection
ITR0 (TS = 000)
TIM15
12 11 10 9
rw rw rw rw
Doc ID 018940 Rev 1
ITR1 (TS = 001)
TIM2
8 7 6 5
UDE BIE TIE COMIE CC4IE
rw rw rw rw
ITR2 (TS = 010) ITR3 (TS = 011)
TIM3
4 3 2
CC3IE CC2IE
rw rw rw
RM0091
TIM17
1 0
CC1IE UIE
rw rw
