RM0091
Table 33.
Name
TRG2
TRG3
TRG4
TRG5
TRG6
TRG7
Note: The trigger selection can not be changed on the fly.
12.5.1

Discontinuous mode (DISCEN)

This mode is enabled by setting the DISCEN bit in the ADC_CFGR1 register.
In this mode (DISCEN=1), a hardware or software trigger event is required to start each
conversion defined in the sequence. On the contrary, if DISCEN=0, a single hardware or
software trigger event successively starts all the conversions defined in the sequence.
Example:
●
DISCEN=1, channels to be converted = 0, 3, 7, 10
–
–
–
–
–
–
–
●
DISCEN=0, channels to be converted = 0, 3, 7, 10
–
–
Note: It is not possible to have both discontinuous mode and continuous mode enabled: it is
forbidden to set both bits DISCEN=1 and CONT=1.
12.5.2

Programmable resolution (RES) - fast conversion mode

It is possible to obtain faster conversion times (t
The resolution can be configured to be either 12, 10, 8, or 6 bits by programming the
RES[1:0] bits in the ADC_CFGR1 register. Lower resolution allows faster conversion times
for applications where high data precision is not required.
The result of the conversion is always 12 bits wide and any unused LSB bits are read as
zeroes.
External triggers (continued)
TIM2_TRGO
TIM3_TRGO
TIM15_TRGO
Reserved
Reserved
Reserved
1st trigger: channel 0 is converted and an EOC event is generated
2nd trigger: channel 3 is converted and an EOC event is generated
3rd trigger: channel 7 is converted and an EOC event is generated
4th trigger: channel 10 is converted and both EOC and EOSEQ events are
generated.
5th trigger: channel 0 is converted an EOC event is generated
6th trigger: channel 3 is converted and an EOC event is generated
...
1st trigger: the complete sequence is converted: channel 0, then 3, 7 and 10.
Each conversion generates an EOC event and the last one also generates an
EOSEQ event.
Any subsequent trigger events will restart the complete sequence.
Doc ID 018940 Rev 1
Source
) by reducing the ADC resolution.
SAR
Analog-to-digital converter (ADC)
EXTSEL[2:0]
010
011
100
101
110
111
179/742
