General-purpose timers (TIM2 and TIM3)
16.4.6

TIM2 and TIM3 event generation register (TIM2_EGR and TIM3_EGR)

Address offset: 0x14
Reset value: 0x0000
15 14 13
Res. Res. Res. Res.
Bits 15:7 Reserved, must be kept at reset value.
Bit 6 TG: Trigger generation
Bit 5 Reserved, must be kept at reset value.
Bit 4 CC4G: Capture/compare 4 generation
Bit 3 CC3G: Capture/compare 3 generation
Bit 2 CC2G: Capture/compare 2 generation
Bit 1 CC1G: Capture/compare 1 generation
Bit 0 UG: Update generation
338/742
12 11 10 9
Res. Res. Res.
This bit is set by software in order to generate an event, it is automatically cleared by
hardware.
0: No action
1: The TIF flag is set in TIMx_SR register. Related interrupt or DMA transfer can occur if
enabled.
Refer to CC1G description
Refer to CC1G description
Refer to CC1G description
This bit is set by software in order to generate an event, it is automatically cleared by
hardware.
0: No action
1: A capture/compare event is generated on channel 1:
If channel CC1 is configured as output:
CC1IF flag is set, Corresponding interrupt or DMA request is sent if enabled.
If channel CC1 is configured as input:
The current value of the counter is captured in TIMx_CCR1 register. The CC1IF flag is set,
the corresponding interrupt or DMA request is sent if enabled. The CC1OF flag is set if the
CC1IF flag was already high.
This bit can be set by software, it is automatically cleared by hardware.
0: No action
1: Re-initialize the counter and generates an update of the registers. Note that the prescaler
counter is cleared too (anyway the prescaler ratio is not affected). The counter is cleared if
the center-aligned mode is selected or if DIR=0 (upcounting), else it takes the auto-reload
value (TIMx_ARR) if DIR=1 (downcounting).
Doc ID 018940 Rev 1
8 7 6 5
Res. Res. TG Res.
w
4 3 2 1
CC4G CC3G CC2G CC1G
w w w w
RM0091
0
UG
w
