RM0091
Moreover, the RDP bytes cannot be programmed. Thus, the level 2 cannot be removed at
all: it is an irreversible operation. When attempting to program the RDP byte, the protection
error flag WRPRTERR is set in the Flash_SR register and an interrupt can be generated.
Note: 1 The debug feature is also disabled under reset.
2 STMicroelectronics is not able to perform analysis on defective parts on which the level 2
protection has been set.
Table 6. Access status versus protection level and execution modes
Protection
Area
level
1
Main Flash
memory
2
1
System
(2)
memory
2
1
Option bytes
2
1
Backup
registers
2
1. When the protection level 2 is active, the Debug port, the boot from RAM and the boot from system memory are disabled.
2. The system memory is only read-accessible, whatever the protection level (0, 1 or 2) and execution mode.
3. The main Flash memory is erased when the RDP option byte is programmed with all level protections disabled (0xAA).
4. All option bytes can be programmed, except the RDP byte.
Changing read protection level
It is easy to move from level 0 to level 1 by changing the value of the RDP byte to any value
(except 0xCC).
By programming the 0xCC value in the RDP byte, it is possible to go to level 2 either directly
from level 0 or from level 1.
On the contrary, the change to level 0 (no protection) is not possible without a main Flash
memory Mass erase operation. This Mass erase is generated as soon as 0xAA is
programmed in the RDP byte.
Note: When the Mass Erase command is used, the backup registers (RTC_BKPxR in the RTC)
are also reset.
To validate the protection level change, the option bytes must be reloaded through the
"OBL_LAUNCH" bit in Flash control register.
3.3.2

Write protection

The write protection is implemented with a granularity of one sector, i.e. four pages. It is
activated by configuring the WRP[1:0] option bytes, and then by reloading them by setting
the OBL_LAUNCH bit in the FLASH_CR register.
User execution
Read Write
Yes Yes
Yes Yes
Yes No
Yes No
(3)
Yes Yes
(4)
Yes Yes
Yes Yes
Yes Yes
Doc ID 018940 Rev 1
Embedded Flash memory
Debug/ BootFromRam/
BootFromLoader
Erase Read
Yes No
(1)
Yes N/A
No Yes
(1)
No NA
Yes Yes
(1)
No N/A
N/A No
(1)
N/A N/A
Write Erase
(3)
No No
(1) (1)
N/A N/A
No No
(1) (1)
N/A N/A
(3)
Yes Yes
(1) (1)
N/A N/A
No Yes
(1) (1)
N/A N/A
51/742
