General-purpose timers (TIM15/16/17)
18.6.8

TIM16 and TIM17 counter (TIM16_CNT and TIM17_CNT)

Address offset: 0x24
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 CNT[15:0]: Counter value
18.6.9

TIM16 and TIM17 prescaler (TIM16_PSC and TIM17_PSC)

Address offset: 0x28
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 PSC[15:0]: Prescaler value
The counter clock frequency (CK_CNT) is equal to f
PSC contains the value to be loaded in the active prescaler register at each update event
(including when the counter is cleared through UG bit of TIMx_EGR register or through trigger
controller when configured in "reset mode").
18.6.10

TIM16 and TIM17 auto-reload register (TIM16_ARR and TIM17_ARR)

Address offset: 0x2C
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 ARR[15:0]: Auto-reload value
ARR is the value to be loaded in the actual auto-reload register.
Refer to the
and behavior.
The counter is blocked while the auto-reload value is null.
432/742
12 11 10 9
rw rw rw rw
12 11 10 9
rw rw rw rw
12 11 10 9
rw rw rw rw
Section 17.3.1: Time-base unit on page 354
Doc ID 018940 Rev 1
8 7 6 5
CNT[15:0]
rw rw rw rw
8 7 6 5
PSC[15:0]
rw rw rw rw
CK_PSC
8 7 6 5
ARR[15:0]
rw rw rw rw
4 3 2
rw rw rw
4 3 2
rw rw rw
/ (PSC[15:0] + 1).
4 3 2
rw rw rw
for more details about ARR update
RM0091
1 0
rw rw
1 0
rw rw
1 0
rw rw
