RM0091
17.4.7

TIM14 counter (TIM14_CNT)

Address offset: 0x24
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 CNT[15:0]: Counter value
17.4.8

TIM14 prescaler (TIM14_PSC)

Address offset: 0x28
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 PSC[15:0]: Prescaler value
The counter clock frequency CK_CNT is equal to f
PSC contains the value to be loaded in the active prescaler register at each update event.
17.4.9

TIM14 auto-reload register (TIM14_ARR)

Address offset: 0x2C
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 ARR[15:0]: Auto-reload value
ARR is the value to be loaded in the actual auto-reload register.
Refer to the
and behavior.
The counter is blocked while the auto-reload value is null.
12 11 10 9
rw rw rw rw
12 11 10 9
rw rw rw rw
12 11 10 9
rw rw rw rw
Section 17.3.1: Time-base unit on page 354
Doc ID 018940 Rev 1
8 7 6 5
CNT[15:0]
rw rw rw rw
8 7 6 5
PSC[15:0]
rw rw rw rw
CK_PSC
8 7 6 5
ARR[15:0]
rw rw rw rw
General-purpose timer (TIM14)
4 3 2
rw rw rw
4 3 2
rw rw rw
/ (PSC[15:0] + 1).
4 3 2
rw rw rw
for more details about ARR update
1 0
rw rw
1 0
rw rw
1 0
rw rw
371/742
