RM0091
1. When both outputs of a channel are not used (CCxE = CCxNE = 0), the OISx, OISxN, CCxP and CCxNP bits must be kept
cleared.
Note:
The state of the external I/O pins connected to the complementary OCx and OCxN
channels depends on the OCx and OCxN channel state and the GPIO registers.
15.4.10
TIM1 counter (TIM1_CNT)
Address offset: 0x24
Reset value: 0x0000
15
14
13
rw
rw
rw
Bits 15:0
CNT[15:0]: Counter value
15.4.11
TIM1 prescaler (TIM1_PSC)
Address offset: 0x28
Reset value: 0x0000
15
14
13
rw
rw
rw
Bits 15:0 PSC[15:0]: Prescaler value
15.4.12
TIM1 auto-reload register (TIM1_ARR)
Address offset: 0x2C
Reset value: 0x0000
15
14
13
rw
rw
rw
Bits 15:0 ARR[15:0]: Auto-reload value
12
11
10
9
rw
rw
rw
rw
12
11
10
9
rw
rw
rw
rw
The counter clock frequency (CK_CNT) is equal to f
PSC contains the value to be loaded in the active prescaler register at each update event
(including when the counter is cleared through UG bit of TIMx_EGR register or through
trigger controller when configured in "reset mode").
12
11
10
9
rw
rw
rw
rw
ARR is the value to be loaded in the actual auto-reload register.
Refer to the
Section 15.3.1: Time-base unit on page 225
and behavior.
The counter is blocked while the auto-reload value is null.
Doc ID 018940 Rev 1
8
7
6
5
CNT[15:0]
rw
rw
rw
rw
8
7
6
5
PSC[15:0]
rw
rw
rw
rw
CK_PSC
8
7
6
5
ARR[15:0]
rw
rw
rw
rw
Advanced-control timers (TIM1)
4
3
2
rw
rw
rw
4
3
2
rw
rw
rw
/ (PSC[15:0] + 1).
4
3
2
rw
rw
rw
for more details about ARR update
1
0
rw
rw
1
0
rw
rw
1
0
rw
rw
283/742
