Table 54. Output control bits for complementary OCx and OCxN channels with break feature
Control bits
MOE bit OSSI bit OSSR bit CCxE bit CCxNE bit OCx output state
1 X
0
0
0
0
1
0
1
1
1
1. When both outputs of a channel are not used (CCxE = CCxNE = 0), the OISx, OISxN, CCxP and CCxNP bits must be kept
cleared.
Note: The state of the external I/O pins connected to the complementary OCx and OCxN
channels depends on the OCx and OCxN channel state and the GPIO and AFIO registers.
