Debug Mcu Configuration Register (Dbgmcu_Cr) - STMicroelectronics STM32F05 series Reference Manual

Debug support (DBG)
29.9.3 Debug MCU configuration register (DBGMCU_CR
This register allows the configuration of the MCU under DEBUG. This concerns:
●
Low-power mode support
This DBGMCU_CR is mapped at address 0x4001 5804.
It is asynchronously reset by the PORESET (and not the system reset). It can be written by
the debugger under system reset.
If the debugger host does not support these features, it is still possible for the user software
to write to these registers.
Address: 0x40015804
Only 32-bit access supported
POR Reset: 0x0000 0000 (not reset by system reset)
31 30 29
Res. Res. Res.
15 14 13
Res. Res. Res.
Bits 31:3 Reserved, must be kept at reset value.
Bit 2 DBG_STANDBY: Debug Standby mode
Bit 1 DBG_STOP: Debug Stop mode
Bit 0 DBG_SLEEP: Debug Sleep mode
728/742
28 27 26 25
Res. Res. Res. Res.
12 11 10 9
Res. Res. Res. Res.
0: (FCLK=Off, HCLK=Off) The whole digital part is unpowered.
From software point of view, exiting from Standby is identical than fetching reset vector
(except a few status bit indicated that the MCU is resuming from Standby)
1: (FCLK=On, HCLK=On) In this case, the digital part is not unpowered and FCLK and
HCLK are provided by the internal RC oscillator which remains active. In addition, the MCU
generate a system reset during Standby mode so that exiting from Standby is identical than
fetching from reset
0: (FCLK=Off, HCLK=Off) In STOP mode, the clock controller disables all clocks (including
HCLK and FCLK). When exiting from STOP mode, the clock configuration is identical to the
one after RESET (CPU clocked by the 8 MHz internal RC oscillator (HSI)). Consequently,
the software must reprogram the clock controller to enable the PLL, the Xtal, etc.
1: (FCLK=On, HCLK=On) In this case, when entering STOP mode, FCLK and HCLK are
provided by the internal RC oscillator which remains active in STOP mode. When exiting
STOP mode, the software must reprogram the clock controller to enable the PLL, the Xtal,
etc. (in the same way it would do in case of DBG_STOP=0)
0: (FCLK=On, HCLK=Off) In Sleep mode, FCLK is clocked by the system clock as previously
configured by the software while HCLK is disabled.
In Sleep mode, the clock controller configuration is not reset and remains in the previously
programmed state. Consequently, when exiting from Sleep mode, the software does not
need to reconfigure the clock controller.
1: (FCLK=On, HCLK=On) In this case, when entering Sleep mode, HCLK is fed by the same
clock that is provided to FCLK (system clock as previously configured by the software).
