Bit 4 DIR: Data transfer direction
This bit is set and cleared by software.
0: Read from peripheral
1: Read from memory
Bit 3 TEIE: Transfer error interrupt enable
This bit is set and cleared by software.
0: TE interrupt disabled
1: TE interrupt enabled
Bit 2 HTIE: Half transfer interrupt enable
This bit is set and cleared by software.
0: HT interrupt disabled
1: HT interrupt enabled
Bit 1 TCIE: Transfer complete interrupt enable
This bit is set and cleared by software.
0: TC interrupt disabled
1: TC interrupt enabled
Bit 0 EN: Channel enable
This bit is set and cleared by software.
0: Channel disabled
1: Channel enabled
10.4.4

DMA channel x number of data register (DMA_CNDTRx) (x = 1..5),

where x = channel number)
Address offset: 0x0C + 0d20 × (channel number – 1)
Reset value: 0x0000 0000
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
rw rw rw rw
Bits 31:16
Bits 15:0 NDT[15:0]: Number of data to transfer
27 26 25
Res. Res. Res.
11 10 9
rw rw rw
Reserved, must be kept at reset value.
Number of data to be transferred (0 up to 65535). This register can only be written when the
channel is disabled. Once the channel is enabled, this register is read-only, indicating the
remaining bytes to be transmitted. This register decrements after each DMA transfer.
Once the transfer is completed, this register can either stay at zero or be reloaded
automatically by the value previously programmed if the channel is configured in auto-reload
mode.
If this register is zero, no transaction can be served whether the channel is enabled or not.
Doc ID 018940 Rev 1
Direct memory access controller (DMA)
24 23 22 21
Res. Res. Res. Res.
8 7 6 5
NDT
rw rw rw rw
20 19 18 17
Res. Res. Res. Res.
4 3 2 1
rw rw rw rw
16
Res.
0
rw
