Analog-to-digital converter (ADC)
12.12
ADC registers
Refer to
12.12.1
ADC interrupt and status register (ADC_ISR)
Address offset: 0x00
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:8 Reserved, must be kept at reset value.
Bit 7 AWD: Analog watchdog flag
This bit is set by hardware when the converted voltage crosses the values programmed in the
ADC_LTR and ADC_HTR registers. It is cleared by software writing 1 to it.
0: No analog watchdog event occurred (or the flag event was already acknowledged and cleared by
software)
1: Analog watchdog event occurred
Bit 6:5 Reserved, must be kept at reset value.
Bit 4 OVR: ADC overrun
This bit is set by hardware when an overrun occurs, meaning that a new conversion has complete
while the EOC flag was already set. It is cleared by software writing 1 to it.
0: No overrun occurred (or the flag event was already acknowledged and cleared by software)
1: Overrun has occurred
Bit 3 EOSEQ: End of sequence flag
This bit is set by hardware at the end of the conversion of a sequence of channels selected by the
CHSEL bits. It is cleared by software writing 1 to it.
0: Conversion sequence not complete (or the flag event was already acknowledged and cleared by
software)
1: Conversion sequence complete
Bit 2 EOC: End of conversion flag
This bit is set by hardware at the end of each conversion of a channel when a new data result is
available in the ADC_DR register. It is cleared by software writing 1 to it or by reading the ADC_DR
register.
0: Channel conversion not complete (or the flag event was already acknowledged and cleared by
software)
1: Channel conversion complete
Bit 1 EOSMP: End of sampling flag
This bit is set by hardware during the conversion, at the end of the sampling phase.
0: Not at the end of the sampling phase (or the flag event was already acknowledged and cleared by
software)
1: End of sampling phase reached
192/742
Section 1.1 on page 34
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
Doc ID 018940 Rev 1
for a list of abbreviations used in register descriptions.
24
23
22
21
Res.
Res.
Res.
Res.
8
7
6
Res.
AWD
Res.
Res.
r_w1
20
19
18
Res.
Res.
Res.
5
4
3
2
OVR
EOSEQ
EOC
r_w1
r_w1
rc_w1
RM0091
17
16
Res.
Res.
1
0
EOSMP ADRDY
r_w1
r_w1
