General-purpose timer (TIM14)
PWM edge-aligned mode
In the following example, we consider PWM mode 1. The reference PWM signal OCxREF is
high as long as TIMx_CNT < TIMx_CCRx else it becomes low. If the compare value in
TIMx_CCRx is greater than the auto-reload value (in TIMx_ARR) then OCxREF is held at
'1'. If the compare value is 0 then OCxRef is held at '0'.
aligned PWM waveforms in an example where TIMx_ARR=8.

Figure 151. Edge-aligned PWM waveforms (ARR=8)

17.3.9

Debug mode

When the microcontroller enters debug mode (Cortex™-M0 core halted), the TIMx counter
either continues to work normally or stops, depending on DBG_TIMx_STOP configuration
bit in DBG module. .
364/742
0 1
Counter register
OCXREF
CCRx=4
CCxIF
OCXREF
CCRx=8
CCxIF
OCXREF
‘
CCRx>8
CCxIF
‘
OCXREF
CCRx=0
CCxIF
Doc ID 018940 Rev 1
Figure 151 shows some edge-
2 3 4 5 6 7
RM0091
8 0 1
