Address offset: 0x24
Reset value: 0x0000 0000
31 30 29
rw rw rw
15 14 13
rw rw rw
Bits 31:16 CNT[31:16]: Most significant part counter value (TIM2 and TIM5)
Bits 15:0 CNT[15:0]: Least significant part of counter value
38.4.13 TIMx counter [alternate] (TIMx_CNT)(x = 2 to 5)
Bit 31 of this register has two possible definitions depending on the value of UIFREMAP in
TIMx_CR1 register:
•
Previous section is for UIFREMAP = 0
•
This section is for UIFREMAP = 1
Address offset: 0x24
Reset value: 0x0000 0000
31 30 29
UIFCPY
rw rw rw
15 14 13
rw rw rw
Bit 31 UIFCPY: UIF Copy
Bits 30:16 CNT[30:16]: Most significant part counter value (TIM2 and TIM5)
Bits 15:0 CNT[15:0]: Least significant part of counter value
38.4.14 TIMx prescaler (TIMx_PSC)(x = 2 to 5)
Address offset: 0x28
Reset value: 0x0000
15 14 13
rw rw rw
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
This bit is a read-only copy of the UIF bit of the TIMx_ISR register
12 11 10 9
rw rw rw rw
General-purpose timers (TIM2/TIM3/TIM4/TIM5)
24 23 22
CNT[31:16]
rw rw rw
8 7 6
CNT[15:0]
rw rw rw
24 23 22
CNT[30:16]
rw rw rw
8 7 6
CNT[15:0]
rw rw rw
8 7 6
PSC[15:0]
rw rw rw
