ADSP-SC58x RTC Trigger List
Table 22-3: ADSP-SC58x RTC Trigger List Masters
Trigger ID Name
134 RTC0_EVT
Table 22-4: ADSP-SC58x RTC Trigger List Slaves
Trigger ID Name
RTC Definitions
The following definitions are helpful when using the RTC module.
RTC HV
The RTC HV is the portion of the RTC which runs on 3.3 V domain and contains the logic for RTC counting/
clock functionality
RTC LV
The RTC LV operates on the core voltage supply and provides the control/access functionality and user interface to
the application
Oscillator
The oscillator is the heart of the RTC. It works with the dedicated external crystal to generate a 32768 Hz signal
which is divided down to a 1Hz clock used to operate the rest of the RTC
RTC Signal Descriptions
The RTC signals are listed in the following table.
Table 22-5: RTC Signal Descriptions
Signal Name
XTALIN
XTALOUT
VDDRTC
RTC Architectural Concepts
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description
RTC0 Event
Description
None
Signal Description
Pin of the dedicated 32.768KHz external crystal
Pin of the dedicated 32.768KHz external crystal
Power supply pin (from Lithium Coin Cell) for RTC module
RTC Functional Description
Sensitivity
Level
Sensitivity
22–3
