Table 22-9: RTC_IEN Register Fields (Continued)
Bit No.
(Access)
6 DAYALM
(R/W)
5 ALM
(R/W)
4 DAY
(R/W)
3 HOUR
(R/W)
2 MIN
(R/W)
1 SEC
(R/W)
0 WRDONE
(R/W)
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Bit Name
Day Alarm Interrupt Enable.
The RTC_IEN.DAYALM bit enables the alarm (day, hour, minute, second) interrupt.
Alarm Interrupt Enable.
The RTC_IEN.ALM bit enables the alarm (hour, minute, second) interrupt.
Days Interrupt Enable.
The RTC_IEN.DAY bit enables the days interrupt.
Hours Interrupt Enable.
The RTC_IEN.HOUR bit enables the hours interrupt.
Minutes Interrupt Enable.
The RTC_IEN.MIN bit enables the minutes interrupt.
Seconds Interrupt Enable.
The RTC_IEN.SEC bit enables the seconds interrupt.
Register Write Done Interrupt Enable.
The RTC_IEN.WRDONE bit enables the interrupt for register write completion. The
RTC_IEN.WRDONE bit is applicable only for the alarm, clock, and stopwatch regis-
ters.
ADSP-SC58x RTC Register Descriptions
Description/Enumeration
0 Disable interrupt
1 Enable interrupt
0 Disable interrupt
1 Enable interrupt
0 Disable interrupt
1 Enable interrupt
0 Disable interrupt
1 Enable interrupt
0 Minute interrupt disabled
1 Enable interrupt
0 Disable interrupt
1 Enable interrupt
0 Disable interrupt
1 Enable interrupt
