LPM Function Address Register
The
USB_LPM_FADDR
Figure 27-96: USB_LPM_FADDR Register Diagram
Table 27-72: USB_LPM_FADDR Register Fields
Bit No.
(Access)
6:0 VALUE
(R/W)
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
register selects the link power management (LPM) function address.
VALUE (R/W)
Function Address Value
Bit Name
Function Address Value.
The USB_LPM_FADDR.VALUE bits hold the LPM function address value that the
USB controller places in the LPM payload.
7 6 5 4 3 2 1 0
0 0 0 0 0 0 0 0
Description/Enumeration
ADSP-SC58x USB Register Descriptions
27–199
