Response Register 0
The register represents bits[31:0] of a long response.
MSI_RESP0
Figure 26-37: MSI_RESP0 Register Diagram
Table 26-40: MSI_RESP0 Register Fields
Bit No.
(Access)
31:0 VALUE
(R/NW)
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
15 14
0 0
VALUE[15:0] (R)
Response Register 0 Value
31 30
0 0
VALUE[31:16] (R)
Response Register 0 Value
Bit Name
Response Register 0 Value.
The MSI_RESP0.VALUE bit field represents bits[31:0] of a long response.
13 12 11 10 9 8 7 6
0 0 0 0 0 0 0 0
29 28 27 26 25 24 23 22
0 0 0 0 0 0 0 0
Description/Enumeration
ADSP-SC58x MSI Register Descriptions
