10 GENERAL-PURPOSE TIMERS

This chapter describes the general-purpose (GP) timer module. Following
an overview and a list of key features is a description of operation and
functional modes of operation. The chapter concludes with a program-
ming model, consolidated register definitions, and programming
examples.

Specific Information for the ADSP-BF50x

For details regarding the number of GP timers for the ADSP-BF50x prod-
uct, refer to ADSP-BF504, ADSP-BF504F, ADSP-BF506F Embedded
Processor Data Sheet.
For GP Timer interrupt vector assignments, refer to
page 4-19 in
To determine how each of the GP Timers is multiplexed with other func-
tional pins, refer to
page 4-19 in
For a list of MMR addresses for each GP Timer, refer to
tem MMR Assignments".
GP timer behavior for the ADSP-BF50x that differs from the general
information in this chapter can be found at the end of this chapter in the
section "Unique Information for the ADSP-BF50x Processor" on
page 10-58.
ADSP-BF50x Blackfin Processor Hardware Reference
Chapter 4, "System
Table 9-1 on page 9-4
Chapter 9, "General-Purpose
Interrupts".
through
Ports".
Table 4-3 on
Table 4-3 on
Chapter A, "Sys-
10-1
