Flowcharts and Pseudo Codes
Figure 6-6. Program Suspend and Resume Flowchart
1 The read status register command (write 0x70) can be issued just before or just after the program re-
sume command.
6-58
START
WRITE 0xB0
WRITE 0x70
READ STATUS REGISTER
NO
SR7 = 1
YES
NO
SR2 = 1
YES
WRITE 0xFF
READ DATA FROM ANOTHER
ADDRESS
WRITE 0xD0
1
WRITE 0x70
PROGRAM CONTINUES WITH
BANK IN READ STATUS
REGISTER MODE
ADSP-BF50x Blackfin Processor Hardware Reference
PROGRAM COMPLETE
WRITE 0xFF
READ DATA
1
