19 SPORT CONTROLLER

This chapter describes the synchronous serial peripheral port (SPORT).
Following an overview and a list of key features is a description of opera-
tion and functional modes of operation. The chapter concludes with a
programming model, consolidated register definitions, and programming
examples.

Specific Information for the ADSP-BF50x

For details regarding the number of SPORTs for the ADSP-BF50x prod-
uct, refer to ADSP-BF504, ADSP-BF504F, ADSP-BF506F Embedded
Processor Data Sheet.
For SPORT DMA channel assignments, refer to
in Chapter 7, "Direct Memory
For SPORT interrupt vector assignments, refer to
in Chapter 4, "System
To determine how each of the SPORTs is multiplexed with other func-
tional pins, refer to
in Chapter 9, "General-Purpose
For a list of MMR addresses for each SPORT, refer to
MMR Assignments".
SPORT behavior for the ADSP-BF50x that differs from the general infor-
mation in this chapter can be found at the end of this chapter in the
section "Unique Information for the ADSP-BF50x Processor" on
ADSP-BF50x Blackfin Processor Hardware Reference
Access".
Interrupts".
Table 9-1 on page 9-4
Ports".
Table 7-7 on page 7-105
Table 4-3 on page 4-19
through Table 9-3 on page 9-6
Chapter A, "System
19-1
