Interface Overview
Figure 19-2. Example SPORT Connections
(SPORT0 is Standard Mode, SPORT1 is Multichannel Mode)
1 In multichannel mode, TFS functions as a transmit data valid (TDV) output. See
eration" on page 19-15.
2 Although shown as an external connection, the TSCLK1/RSCLK1 connection is internal in multi-
channel mode. See "Multichannel Operation" on page
19-8
SERIAL
DEVICE B
(SECONDARY)
SERIAL SERIAL
DEVICE N DEVICE 2
ADSP-BF50x Blackfin Processor Hardware Reference
BLACKFIN
SPORT0
TSCLK0
TFS0
RSCLK0
RFS0
SERIAL
DT0PRI
DEVICE A
DR0PRI
(PRIMARY)
DT0SEC
DR0SEC
SPORT1
TSCLK1
RSCLK1
TFS1 (TDV1)
RFS1
DT1PRI
DR1PRI
DT1SEC
DR1SEC
SERIAL
DEVICE 1
19-15.
1, 2
"Multichannel Op-
