CAN Register Definitions

CAN_MBxx_LENGTH Registers

Mailbox Word 4 Register (CAN_MBxx_LENGTH)
15 14 13 12 11 10
X
For memory-
mapped
addresses, see
Table 17-25.
Figure 17-25. Mailbox Word 4 Register
Table 17-15. Mailbox Word 4 Register Memory-Mapped
Addresses
Register Name
CAN_MB00_LENGTH
CAN_MB01_LENGTH
CAN_MB02_LENGTH
CAN_MB03_LENGTH
CAN_MB04_LENGTH
CAN_MB05_LENGTH
CAN_MB06_LENGTH
CAN_MB07_LENGTH
CAN_MB08_LENGTH
CAN_MB09_LENGTH
CAN_MB10_LENGTH
CAN_MB11_LENGTH
CAN_MB12_LENGTH
CAN_MB13_LENGTH
CAN_MB14_LENGTH
CAN_MB15_LENGTH
CAN_MB16_LENGTH
17-58
9 8 7
X X X X X X X X
Memory-Mapped Address
0xFFC0 2C10
0xFFC0 2C30
0xFFC0 2C50
0xFFC0 2C70
0xFFC0 2C90
0xFFC0 2CB0
0xFFC0 2CD0
0xFFC0 2CF0
0xFFC0 2D10
0xFFC0 2D30
0xFFC0 2D50
0xFFC0 2D70
0xFFC0 2D90
0xFFC0 2DB0
0xFFC0 2DD0
0xFFC0 2DF0
0xFFC0 2E10
ADSP-BF50x Blackfin Processor Hardware Reference
6 5 4 3 2 1 0
X X X X X X X
Reset = 0xXXXX
DLC[3:0] (Data Length Code)
