Database Administration Manual - IP7 Secure
Gateway
3. Display the association that will be changed by entering the rtrv-assoc command with the name
of the association. For this example, enter this command.
rtrv-assoc:aname=assoc1
This is an example of the possible output.
rlghncxa03w 09-05-28 21:14:37 GMT EAGLE5 41.0.0
ANAME assoc1
LOC
ADAPTER
LHOST
ALHOST
RHOST
ARHOST
LPORT
ISTRMS
RMODE
RTIMES
OPEN
RHOSTVAL RELAXED
ASNAMES
as1
IP Appl Sock/Assoc table is (8 of 4000) 1% full
Assoc Buffer Space Used (800 KB of 800 KB) on LOC = 1201
4. Enter the ping pass command specifying the card location of the local host, shown in
the name of the remote host assigned to the association being changed, shown in
This command is entered several times to obtain the average round trip time. For this example,
enter this command.
pass:loc=1201:cmd= ping gw100.nc.tekelec.com
The following is an example of the possible output
rlghncxa03w 06-10-28 21:15:37 GMT EAGLE5 36.0.0
PASS: Command sent to card
rlghncxa03w 06-10-28 21:15:37 GMT EAGLE5 36.0.0
PING command in progress
rlghncxa03w 06-10-28 21:15:37 GMT EAGLE5 36.0.0
PING GW100. NC. TEKELEC. COM (192.1.1.30): 56 data bytes
64 bytes from tekral.nc.tekelec.com (192.1.1.30): icmp_seq=0. time=5. ms
64 bytes from tekral.nc.tekelec.com (192.1.1.30): icmp_seq=1. time=9. ms
64 bytes from tekral.nc.tekelec.com (192.1.1.30): icmp_seq=2. time=14. ms
----tekral PING Statistics----
3 packets transmitted, 3 packets received, 0% packet loss
round-trip (ms)
PING command complete
If the SCTP retransmission parameters are not to be changed, do not perform
8. This procedure is finished.
5. Perform the Changing the Attributes of a M3UA or SUA Association
retransmission parameters of the association based on the results of pinging the remote host.
6. Enter the assocrtt pass command to display the round trip time data collected after an association
is established when an SCTP INIT message is sent and an acknowledgment is received.
910-6278-001 Revision A, January 2012
1201 IPLNK PORT
M3UA VER
IPNODE2-1205
---
gw100.nc.tekelec.com
---
2000 RPORT
2 OSTRMS
LIN RMIN
10 CWMIN
YES ALW
as4
min/avg/max = 5/9/14
IETF M3UA and SUA Configuration Procedures
A LINK
M3UA RFC
1030
2 BUFSIZE
120 RMAX
3000 UAPS
YES RTXTHR
as6
procedure to change the
A
200
800
10
2000
Step 3 , and
Step 3 .
Step 5 through Step
