Database Administration Manual - IP7 Secure
Gateway
This is an example of the possible output.
rlghncxa03w 06-10-10 11:43:04 GMT EAGLE5 37.5.0
DPCA
010-020-005
DESTINATION ENTRIES ALLOCATED:
FULL DPC(s):
EXCEPTION DPC(s):
NETWORK DPC(s):
CLUSTER DPC(s):
TOTAL DPC(s):
CAPACITY (% FULL):
ALIASES ALLOCATED:
ALIASES USED:
CAPACITY (% FULL):
X-LIST ENTRIES ALLOCATED:
If the adjacent point code of the linkset is not the DPC of a route exception table entry, no entries
are displayed in the rtrv-rtx output, but a summary of the point code quantities is displayed,
as shown in the following output example.
rlghncxa03w 06-10-10 11:43:04 GMT EAGLE5 37.5.0
DESTINATION ENTRIES ALLOCATED:
FULL DPC(s):
EXCEPTION DPC(s):
NETWORK DPC(s):
CLUSTER DPC(s):
TOTAL DPC(s):
CAPACITY (% FULL):
ALIASES ALLOCATED:
ALIASES USED:
CAPACITY (% FULL):
X-LIST ENTRIES ALLOCATED:
If the point code specified in this step is shown in the DPCA/DPCI/DPCN/ DPCN24 columns in this
step, the point code value cannot be used as an adjacent point code unless one of two actions are
taken:
Choose another adjacent point code value and repeat the procedure from
Remove all the entries displayed in this step by performing the "Removing a Route Exception
Entry" procedure in the Database Administration Manual - SS7 . After the entries have been
removed, continue the procedure with
If the adjacent point code of the linkset is not the DPC of a route exception table entry, continue
the procedure with
6. Display any entries in the route table whose DPC value is also the adjacent point code of the new
linkset being added in this procedure, or the new adjacent point code of the existing linkset being
changed in this procedure. Enter the rtrv-rte command with the dpc/dpca/dpci/dpcn/dpcn24
parameter. The dpc/dpca/dpci/dpcn/dpcn24 parameter value is the adjacent point code value
that will be specified for the linkset. For this example, enter this command.
rtrv-rte:dpca=010-020-005
910-6278-001 Revision A, January 2012
RTX-CRITERIA
OPCA
007-008-009
008-008-008
2000
12000
Step 6.
IPSG M2PA and M3UA Configuration Procedures
LSN
ls1305
ls1307
13
5
0
1
19
1%
0
0%
500
2000
15
5
0
1
21
1%
12000
0
0%
500
Step 6.
RC APC
20 001-005-000
40 001-007-000
Step 2.
657
