Database Administration Manual - IP7 Secure
Gateway
When this command has successfully completed, this message should appear.
rlghncxa03w 06-10-23 13:05:05 GMT EAGLE5 36.0.0
Card has been allowed.
18. Activate all signaling links on the cards using the act-slk command, specifying the card location
and link parameter value of each signaling link. For this example, enter this command.
act-slk:loc=2204:link=a10
When this command has successfully completed, this message should appear.
rlghncxa03w 06-10-07 08:31:24 GMT
Activate Link message sent to card
19. Check the status of the signaling links added in
the card location and link parameter values specified in
should be in service normal (IS-NR) after the link has completed alignment (shown in the PST
field). For this example, enter these commands.
rept-stat-slk:loc=2204:link=a10
This is an example of the possible output.
rlghncxa03w 07-05-23 13:06:25 GMT EAGLE5 37.0.0
SLK
LSN
2204,A10 lsipgw
ALARM STATUS
UNAVAIL REASON
If the OPEN value of the association that was assigned to the signaling link is yes, continue the
procedure with
If the OPEN value of the association that was assigned to the signaling link is nos, continue the
procedure with
20. Change the open parameter value of the association that was assigned to the signaling link by
entering the chg-assoc command with the open=yes parameter and the name of the association
that was association. For this example, enter this command.
chg-assoc:aname=m3ua4:open=yes
When this command has successfully completed, this message should appear.
rlghncxa03w 06-10-07 08:29:03 GMT
CHG-ASSOC: MASP A - COMPLTD
21. Back up the new changes using the chg-db:action=backup:dest=fixed command. These
messages should appear, the active Maintenance and Administration Subsystem Processor (MASP)
appears first.
BACKUP (FIXED) : MASP A - Backup starts on active MASP.
BACKUP (FIXED) : MASP A - Backup on active MASP to fixed disk complete.
BACKUP (FIXED) : MASP A - Backup starts on standby MASP.
BACKUP (FIXED) : MASP A - Backup on standby MASP to fixed disk complete.
910-6278-001 Revision A, January 2012
CLLI
PST
----------- IS-NR
=
=
Step
21.
Step
20.
IPSG M2PA and M3UA Configuration Procedures
EAGLE5 36.0.0
Step 15
using the rept-stat-slk command with
Step
15.The state of each signaling link
SST
Avail
EAGLE5 36.0.0
AST
----
787
