Database Administration Manual - IP7 Secure
Gateway
Sheet 4
Sheet 6 of 6

Figure 45: Adding a Mate IPGWx Linkset to another IPGWx Linkset

910-6278-001 Revision A, January 2012
Enter the dact-slk command with
these parameters:
From
:loc=<the card location used in the
Sheet 5
rept-stat-slk command on Sheet 4>
From
Change the existing IPGWx linkset
with the chg-ls command and these
mandatory parameters:
:lsn=<linkset name being changed>
:matelsn = <mate linkset name>
:action=add
Enter the rtrv-ls command
with this parameter:
:lsn=<the linkset name that
was changed>
Was a signaling
link taken out of
service?
No
Enter the
chg-db:action=backup:dest=fixed
command
IETF M3UA and SUA Configuration Procedures
Enter the inh-card command
:loc=<the card location used
in the dact-slk command>
:link=a
Enter the alw-card command with this
parameter:
:loc=<the card location used in the inh-card
command>
Enter the act-slk command with these
parameters:
:loc=<the card location used in the
dact-slk command>
Yes
Were the alw
and open parameter values
for any associations changed
on Sheet 5?
Have the far-end node for the
IPGWx signaling link put back into
service the IP connections that
were placed out of service on
Sheet 5.
Have the far-end node place the
M3UA or SUA associations in the
ASP-ACTIVE state.
with this parameter:
:link=a
Yes
No
Enter the chg-assoc
:aname=<association name>
:open=yes:alw=yes
command.
Repeat this step for all
associations whose open or
alw parameter values were
changed on Sheet 5.
317
