Database Administration Manual - IP7 Secure
Gateway
rept-stat-card:loc=1303
This is an example of possible output.
rlghncxa03w 10-12-28 09:12:36 GMT EAGLE5 43.0.0
CARD VERSION
1303 133-003-000
ALARM STATUS
BLIXP GPL version = 133-003-000
IMT BUS A
IMT BUS B
CURRENT TEMPERATURE
PEAK TEMPERATURE:
SIGNALING LINK STATUS
SLK
A
B
Command Completed.
If the TYPE value for the card is not ENET, this card is not an E5-ENET card. Choose another card
from the rtrv-card output in
If the TYPE value for the card is ENET, this card is an E5-ENET card.
If signaling links are not assigned to the card, this procedure cannot be performed. To make this
card an IPSG card, perform the
After the card has been removed from the database, perform the procedures in
M3UA Configuration Procedures
If signaling links are assigned to the card, continue the procedure by performing one of these steps.
If the state of all the signaling links that are assigned to the card is OOS-MT-DSBLD and the
state of the card is OOS-MT-DSBLD, continue the procedure with
If the state of all the signaling links that are assigned to the card is OOS-MT-DSBLD, but the
state of the card is not OOS-MT-DSBLD, continue the procedure with
If the state of any of the signaling links that are assigned to the card is not OOS-MT-DSBLD,
continue the procedure with
3. Place the signaling links shown in
entering the dact-slk command with the card location shown in the CARD column of the
rept-stat-card output, and link value of the signaling link shown in the SLK column of the
rept-stat-card output.
For this example, enter these commands.
dact-slk:loc=1303:link=a
dact-slk:loc=1303:link=b
When these commands have successfully completed, this message appears.
rlghncxa03w 10-07-17 11:43:04 GMT EAGLE5 42.0.0
Deactivate Link message sent to card.
Continue the procedure by performing one of these steps.
If the state of the card is OOS-MT-DSBLD, continue the procedure with
If the state of the card is not OOS-MT-DSBLD, continue the procedure with
910-6278-001 Revision A, January 2012
TYPE GPL
ENET IPLIM
= No Alarms.
= Conn
= Conn
= 32C ( 90F)
= 39C (103F)
PST
IS-NR
IS-NR
Step 1 and repeat this step.
Removing an IPLIMx Card
to configure an IPSG card with IPSG M2PA signaling links.
Step 3.
Step 2
IPSG M2PA and M3UA Configuration Procedures
PST
IS-NR
[ALARM TEMP:
[06-05-02 13:40]
LS CLLI
ipnode1 -----------
ipnode3 -----------
to remove the card from the database.
whose state is not OOS-MT-DSBLD out of service by
SST AST
Active -----
60C (140F)]
IPSG M2PA and
Step 5.
Step 4.
Step 5.
Step 4.
