Database Administration Manual - IP7 Secure
Gateway
These procedures in the Database Administration Manual - SS7
Adding an SS7 Linkset
Changing an SS7 Linkset
Configuring an ITU Linkset with a Secondary Adjacent Point Code (SAPC)
The "Configuring a Linkset for the GSM MAP Screening Feature" procedure in the Database
Administration Manual - Features.
Note: The mtprse, spc/spca/spci/spcn/spcn24, sapci/sapcn/sapcn24, and
ppc/ppca/ppci/ppcn/ppcn24 parameters cannot be specified for an IPSG M3UA linkset.
Canceling the RTRV-LS Command
Because the rtrv-ls command used in this procedure can output information for a long period of
time, the rtrv-ls command can be canceled and the output to the terminal stopped. There are three
ways that the rtrv-ls command can be canceled.
Press the F9 function key on the keyboard at the terminal where the rtrv-ls command was
entered.
Enter the canc-cmd without the trm parameter at the terminal where the rtrv-ls command
was entered.
Enter the canc-cmd:trm=<xx>, where <xx> is the terminal where the rtrv-ls command was
entered, from another terminal other that the terminal where the rtrv-ls command was entered.
To enter the canc-cmd:trm=<xx> command, the terminal must allow Security Administration
commands to be entered from it and the user must be allowed to enter Security Administration
commands. The terminal's permissions can be verified with the rtrv-secu-trm command. The
user's permissions can be verified with the rtrv-user or rtrv-secu-user commands.
For more information about the canc-cmd command, go to the Commands Manual.
1. Display the current linksets in the database using the rtrv-ls command.
This is an example of the possible output.
rlghncxa03w 08-04-10 11:43:04 GMT EAGLE5 38.0.0
LSN
e1e2
e1m1s1
e1m1s2
ls1305
ls1307
lsgw1101
lsgw1103
lsgw1105
LSN
e1e2i
ls1315
ls1317
e1m2s1
e1m2s2
Link set table is (13 of 1024) 1% full.
2. Display a linkset shown in
shown in Step
910-6278-001 Revision A, January 2012
APCA (SS7) SCRN
001-207-000 none
001-001-001 none
001-001-002 none
001-005-000 none
001-007-000 none
008-012-003 none
003-002-004 none
009-002-003 none
APCI (SS7) SCRN
1-207-0 none
0-015-0 none
0-017-0 none
1-011-1 none
1-011-2 none
Step 1 by entering the rtrv-ls command with the name of the linkset
1. For this example, enter these commands.
IPSG M2PA and M3UA Configuration Procedures
L3T SLT
SET SET BEI LST LNKS ACT MES DIS SLSCI NIS
1 1 no B 6
1 1 no A 7
1 1 no A 7
1 1 no A 1
1 1 no A 1
1 1 no A 1
1 1 no A 1
1 1 no A 1
L3T SLT
SET SET BEI LST LNKS ACT MES DIS SLSCI NIS
1 1 no B 4
1 1 no A 1
1 1 no A 1
1 1 no A 7
1 1 no A 7
GWS GWS GWS
off off off no off
off off off no off
off off off no off
off off off no off
off off off no off
off off off no off
off off off no off
off off off no off
GWS GWS GWS
off off off --- on
off off off --- off
off off off --- on
off off off --- off
off off off --- off
