Database Administration Manual - IP7 Secure
Gateway
Sheet 5 of 5

Figure 92: Adding an IPSG M2PA Linkset

910-6278-001 Revision A, January 2012
From
Sheets 2,
3, or 4
Add the IPSG M2PA linkset with the ent-ls command and
these mandatory parameters:
:lsn = <linkset name, not shown in the rtrv-ls output>
:apc/apca/apci/apcn/apcn24 = <adjacent point code shown in
the rtrv-dstn output, but not shown in the rtrv-sid output>
:lst = <a, b, c, d, e>
:ipsg = yes
:adapter = m2pa
:maxslktps = <100 - 5000>
:rsvdslktps = <0 - 5000>
and with any of these optional parameters.
:tpsalmtype = <rsvdslktps, maxslktps> Default value = rsvdslktps
:lsusealm = <10 - 100> Default value = 100
:slkusealm = <10 - 100> Default value = 80
Notes:
1. The maxslktps parameter value must be greater than or
equal to the rsvdslktps parameter value.
2. The slktps parameter can be used in place of the rsvdslktps
parameter.
There are other optional parameters that can be specified with
the ent-ls command. See the Other Optional Parameters"
section in the Adding an IPSG M2PA Linkset" Procedure in the
Database Administration Manual
procedures that discuss these parameters and their usage.
Enter the rtrv-ls command
with this parameter.
:lsn=<linkset name specified
in the ent-ls command>
Enter the
chg-db:action=backup:dest=fixed
command.
IPSG M2PA and M3UA Configuration Procedures
IP7 Secure Gateway for the
670
