Tekelec IP7 Secure Gateway Administration Manual page 734

Database Administration Manual - IP7 Secure
Gateway
192.1.1.50
192.1.1.52
REMOTE IPADDR
150.1.1.5
IP Host table is (11 of 2048) 1% full
The IP address of the IP link should be assigned to the local host name that will be assigned to the
association.
The values of the lhost and alhost parameters must be in the LOCAL HOST column in the
rtrv-ip-host output.
If the required hostname is not in the database, add the IP host name using the
procedure.
6. Verify the values of the M2PA timer set you wish to assign to the association by entering the
rtrv-m2pa-tset command with the ver=rfc parameter.
When an IPSG M2PA association is provisioned in this procedure, the RFC M2PA version is
assigned to the IPSG M2PA association by default.
The M2PA version of the association determines the version of the M2PA timer set that is assigned
to the association. For example, if M2PA timer set 3 is assigned to the IPSG M2PA association, and
the association is an RFC IPSG M2PA association, the RFC version of M2PA timer set 3 is used
with the association. If M2PA timer set 7 is assigned to the IPSG M2PA association, and the
association is a Draft 6 IPSG M2PA association, the Draft 6 version of M2PA timer set 7 is used
with the association.
If you wish to assign the Draft 6 M2PA version to this association and use the Draft 6 M2PA timer
sets, perform the
completed to change the M2PA version of this association.
Note: If the m2patset parameter will not be specified with the ent-assoc command, the M2PA
timer set 1 will be assigned to the association.
To display the M2PA Draft 6 timer values, enter this command.
rtrv-m2pa-tset:ver=d6
This is an example of the possible output.
rlghncxa03w 08-04-28 21:16:37 GMT EAGLE5 38.0.0
M2PA Draft 6 Timers (in msec, T16 in microsec)
TSET T1
1 6000
2 7500
3 100000 ------ 2000
4 200000 ------ 20000 4000
5 250000 ------ 30000 30000 500
6 50000
7 10000
8 80000
9 27500
10 90000
11 20000
12 30000
13 40000
14 70000
15 9000
910-6278-001 Revision A, January 2012
DN-MSC1
DN-MSC2
REMOTE HOST
NCDEPTECONOMIC_DEVELOPMENT. SOUTHEASTERN_COORIDOR_ASHVL. GOV
Changing the Attributes of an IPSG Association
T2 T3 T4N
------ 5000 20000 500
------ 1500 2000
3000
------ 50000 60000 500
------ 10000 10000 500
------ 1500 15000 500
------ 3850 4859
------ 2500 50000 500
------ 4500 5500
------ 7500 7000
------ 35000 9000
------ 45000 11000 500
------ 25000 40000 500
IPSG M2PA and M3UA Configuration Procedures
T4E T5 T6 T7
5000 4000 1000
500 9000 1250 300
500 4000 1500 500
500 6000 2000 700
100 2250 400
500 4500 800
1000 3000 1200
8000 2750 1100
450 5700 3750 1150
7500 5000 1750
500 6500 5500 1600
500 750 4250 1800
500 1250 3500 1900
1500 1750 900
2500 3250 600
Adding an IP Host
procedure after this procedure is
T16 T17 T18
100000 150 500
150000 175 600
170000 200 800
480000 225 900
400000 400 8000
300000 300 7000
200000 250 1000
350000 350 5000
250 375 8750
440000 450 3000
250000 475 4500
275000 275 3500
500 325 9000
1000 125 6000
5000 425 5500
734
