Database Administration Manual - IP7 Secure
Gateway
Requirements for EAGLE 5 ISSs Containing more than 1200 Signaling
Links
To provision an EAGLE 5 ISS with more than 1200 signaling links (currently the EAGLE 5 ISS can
have maximum capacities of 1200, 1500, 2000, or 2800 signaling links), the following additional
requirements must be met:
The Measurements Platform feature must be enabled. Perform these procedures in the Database
Administration Manual - System Management to enable the Measurements Platform Feature:
Adding an MCPM
Configuring the IP Communications Link for the Measurements Platform Feature
Adding an FTP Server
To provision more than 1200 signaling links, the Large System # Links controlled feature must be
enabled for 1500, 2000, or 2800 signaling links. For more information on enabling this feature, go
Enabling the Large System # Links Controlled Feature
to the

Determining the Number of High-Speed and Low-Speed Signaling Links

The EAGLE 5 ISS can contain these quantities of signaling links.
The maximum number of IP signaling links (signaling links assigned to IPLIMx cards, IPGWx
cards, or IPSG cards) or ATM high-speed signaling links (signaling links (signaling links assigned
to cards running either ATMANSI or ATMITU applications), is limited by the total provisioned
system TPS (transactions per second). If the HIPR2 High Rate Mode feature is not enabled or turned
on, the total provisioned system TPS is 500,000 TPS. If the HIPR2 High Rate Mode feature is enabled
and turned on, the total provisioned system TPS is 750,000 TPS. The total provisioned system TPS
is shown in the rtrv-tps output. The EAGLE 5 ISS supports these quantities.
187 IPLIMx cards with each card supporting 4000 TPS. An IPLIMx card can contain up to 16
signaling links. For more information about configuring an IPLIMx signaling link, see the
Adding an IPLIMx Signaling Link
IPLIMx cards but not all the IPLIMx cards can contain provisioned signaling links.
187 IPGWx cards with each card supporting 4000 TPS. An IPGWx card can contain one signaling
link. For more information about configuring an IPGWx signaling link, see the
Signaling Link
TPS that is assigned to some of the IPGWx cards is less than 4000, and there are no other types
of cards are in the database other than the control cards.
150 IPSG cards with each card supporting 5000 TPS. An IPSG card can contain up to 32 signaling
links. For more information about configuring an IPSG signaling link, see the
M2PA Signaling
EAGLE 5 ISS can support a maximum of 250 IPSG cards if the TPS that is assigned to some of
the IPSG cards is less than 5000, and there are no other types of cards are in the database other
than the control cards.
The amount of TPS for an ANSI ATM high-speed signaling link is 1630. The amount of TPS for
an ITU ATM high-speed signaling link is 2038. The EAGLE 5 ISS supports a maximum of 460
910-6278-001 Revision A, January 2012
procedure. The EAGLE 5 ISS can support a maximum of 250
procedure. The EAGLE 5 ISS can support a maximum of 250 IPGWx cards if the
Linkprocedure or the
procedure.
Adding an IPSG M3UA Signaling
Reference Information
Adding an IPGWx
Adding an IPSG
Linkprocedure. The
1032
