Database Administration Manual - IP7 Secure
Gateway
Destination table is (14 of 2000) 1% full
Alias table is (0 of 12000) 0% full
This point code cannot be a proxy point code (the prx=yes value assigned to the point code) and
a proxy point code (a point code value is shown in the PPC column) cannot be assigned to the point
code. If a proxy point code is shown in this step, or if the point code is a proxy point code, choose
another point code and repeat this procedure from
If a proxy point code is not shown in this step, or if the point code is not a proxy point code, continue
this procedure with
5. The APC of the linkset cannot be the DPC of any exception route. Verify that the adjacent point
code of the linkset is not the DPC of any exception route by entering the rtrv-rtx command with
the dpc/dpca/dpci/dpcn/dpcn24 parameter. The dpc/dpca/dpci/dpcn/dpcn24 parameter
value is the adjacent point code value that will be specified for the linkset.
For this example, enter this command.
rtrv-rtx:dpca=010-020-005
This is an example of the possible output.
rlghncxa03w 06-10-10 11:43:04 GMT EAGLE5 37.5.0
DPCA
010-020-005
DESTINATION ENTRIES ALLOCATED:
FULL DPC(s):
EXCEPTION DPC(s):
NETWORK DPC(s):
CLUSTER DPC(s):
TOTAL DPC(s):
CAPACITY (% FULL):
ALIASES ALLOCATED:
ALIASES USED:
CAPACITY (% FULL):
X-LIST ENTRIES ALLOCATED:
If the adjacent point code of the linkset is not the DPC of a route exception table entry, no entries
are displayed in the rtrv-rtx output, but a summary of the point code quantities is displayed,
as shown in the following output example.
rlghncxa03w 06-10-10 11:43:04 GMT EAGLE5 37.5.0
DESTINATION ENTRIES ALLOCATED:
FULL DPC(s):
EXCEPTION DPC(s):
NETWORK DPC(s):
CLUSTER DPC(s):
TOTAL DPC(s):
CAPACITY (% FULL):
ALIASES ALLOCATED:
ALIASES USED:
CAPACITY (% FULL):
X-LIST ENTRIES ALLOCATED:
If the point code specified in this step is shown in the DPCA/DPCI/DPCN/ DPCN24 columns in this
step, the point code value cannot be used as an adjacent point code unless one of two actions are
taken:
910-6278-001 Revision A, January 2012
Step 5.
RTX-CRITERIA
OPCA
007-008-009
008-008-008
2000
12000
500
IPSG M2PA and M3UA Configuration Procedures
Step 2.
LSN
ls1305
ls1307
13
5
0
1
19
1%
0
0%
2000
15
5
0
1
21
1%
12000
0
0%
500
RC APC
20 001-005-000
40 001-007-000
