Database Administration Manual - IP7 Secure
Gateway
IP Host table is (11 of 2048) 1% full
The IP address of the IP link should be assigned to the local host name that will be assigned to the
association.
The values of the lhost and alhost parameters must be in the LOCAL HOST column in the
rtrv-ip-host output.
If the required hostname is not in the database, add the IP host name using the
procedure.
6. Verify the available buffer size for the IP card that will contain the association being added in this
procedure by entering the rtrv-assoc command with the local host name assigned to the
association being added. For this example, enter this command.
Note: If a new IP host was added in
rtrv-assoc:lhost="IPNODE2-1305"
This is an example of the possible output.
rlghncxa03w 06-10-28 09:12:36 GMT EAGLE5 36.0.0
ANAME
a2
IP Appl Sock/Assoc table is (8 of 4000) 1% full
Assoc Buffer Space Used (16 KB of 800 KB) on LOC = 1305
If adding the new association causes the total buffer size for all the associations on the IP card to
exceed the maximum buffer size for that IP card, the ent-assoc command will be rejected.
The default buffer value for an M3UA or SUA association is 16.
If the you wish to add the association and the maximum buffer size for the IP card will be exceeded,
the buffer size of the other associations assigned to the IP card must be decreased by performing
the Changing the Buffer Size of an IPSG Association
7. Add the associations using the ent-assoc command. For this example, enter these commands.
ent-assoc:aname=assoc1:lhost=gw105.nc.tekelec.com:lport=1030:
rhost=gw100.nc.tekelec.com:rport=1030:adapter=m3ua
These are the rules that apply to adding IPSG M3UA associations.
1. The EAGLE 5 ISS can contain a maximum of 4000 connections (association – application server
assignments).
2. A maximum of 32 IPSG M2PA or M3UA associations can be assigned to the IPSG card.
3. The value of the lhost, rhost, or alhost parameters is a text string of up to 60 characters,
with the first character being a letter. The command line on the terminal can contain up to 150
characters. If the host names are too long to fit on the ent-assoc command line, perform the
chg-assoc command with the parameters and values necessary to complete the entry of the
IPSG M3UA association.
4. To activate the association after the association is assigned to a signaling link, the association
must contain values for the lhost, rhost, lport, and rport parameters.
5. If the lhost and alhost parameters are specified, the lhost parameter value represents the
IP address corresponding to one of the network interfaces (A or B) on the IP card while the
910-6278-001 Revision A, January 2012
Step 5, continue the procedure with
CARD IPLNK
LOC PORT LINK ADAPTER LPORT RPORT OPEN ALW
1305 A A SUA
IPSG M2PA and M3UA Configuration Procedures
1030 2345 YES
procedure.
Adding an IP Host
Step 7.
YES
