Database Administration Manual - IP7 Secure
Gateway
3 1
3 2
3 3
3 4
3 5
3 6
3 7
3 8
3 9
3 10
TIMER 2: False IP Connection Congestion Timer, max time an
association can be congested before failing due to false
congestion. SS7IPGW and IPGWI applications enforce
0-30000(ms). Not supported on IPSG application.
TVALUE : Valid range = 32-bits
TIMER 3: UA HeartBeat Period Timer T(beat), time (ms) between sending
of BEAT msgs by NE. IPSG, SS7IPGW and IPGWI applications
enforce 100(ms)-60000(ms).
TVALUE : Valid range = 32-bits
TIMER 4: UA HeartBeat Received Timer T(beat ack), timeout period for
response BEAT ACK msgs by NE. IPSG, SS7IPGW and IPGWI
applications enforce 100(ms)-10000(ms).
TVALUE : Valid range = 32-bits
PARM 1: ASP SNM options.
flag for a particular ASP SNM option. Not supported on IPSG
application.
PVALUE : Valid range = 32-bits
BIT
0=Broadcast
1=Response Method
2-5=Reserved
6=Broadcast Congestion Status Change 0=Disabled , 1=Enabled
7-31=Reserved
PARM 2: ASP/AS Notification options.
enabled/disabled flag for a particular ASP/AS
Notification option.
PVALUE : Valid range = 32-bits
BIT
0=ASP Active Notifications
1=ASP Inactive Notifications
2=ASP AS State Query
3-31=Reserved
PARM 3: UA Serviceability Options.
enabled/disabled flag for a particular UA Serviceability
option. Supported on IPSG, SS7IPGW, and IPGWI applications.
UA Graceful Shutdown supported on IPSG for M3UA only.
PVALUE : Valid range = 32-bits
BIT
0=UA Heartbeats
1=UA Graceful Shutdown
2-31=Reserved
PARM 4: SCTP Payload Protocol Indicator byte order option. Bit indicates
PPI value is RCV/TX in Big Endian or Little Endian byte format.
Supported on IPSG-M2PA associations only.
PVALUE : Valid range = 32-bits
BIT
910-6278-001 Revision A, January 2012
10 1
3000 2
10000 3
5000 4
0 5
0 6
0 7
0 8
0 9
0 10
Each bit is used as an enabled/disabled
Not supported on IPSG application.
IETF M3UA and SUA Configuration Procedures
3
0
1
0
0
0
0
0
0
0
BIT VALUE
0=Disabled , 1=Enabled
0=Disabled , 1=Enabled
Each bit is used as an
BIT VALUE
0=Disabled , 1=Enabled
0=Disabled , 1=Enabled
0=Disabled , 1=Enabled
Each bit is used as an
BIT VALUE
0=Disabled , 1=Enabled
0=Disabled , 1=Enabled
BIT VALUE
518
