Database Administration Manual - IP7 Secure
Gateway
ADAPTER
m3ua
NUMSLKALW
1
LOC
2207 A
Link set table is (22 of 1024) 2% full.
The IPSG M3UA signaling link cannot be removed if removing the IPSG M3UA signaling link will
cause the number of IS-NR IPSG M3UA signaling links in the linkset to be less than the NUMSLKALW,
NUMSLKRSTR, and NUMSLKPROH values shown in the rtrv-ls output. If the NUMSLKALW,
NUMSLKRSTR, and NUMSLKPROH values are 1 or 0, then the IPSG M3UA signaling link can be
removed. The value 0 is shown in the rtrv-ls output as a number with an asterisk (*) is displayed
in the rtrv-ls output, for example, 2*.
If you do not wish to change the NUMSLKALW, NUMSLKRSTR, or NUMSLKPROH values, this signaling
link cannot be removed and the remainder of this procedure cannot be performed.
If you with to change the NUMSLKALW, NUMSLKRSTR, or NUMSLKPROH values, perform the
Configuring IPSG M3UA Linkset Options
Configuring IPSG M3UA Linkset Options
4. Any in-service IP connections on the signaling link being removed in this procedure must be placed
out of service.
Have the far-end node for the signaling link being removed place the M3UA associations in either
the ASP-INACTIVE or ASP-DOWN state.
If the OPEN or ALW values for the associations is YES, continue the procedure with
If the OPEN and ALW values for the associations is NO, continue the procedure with
5. Change the value of the open and alw parameters to no by specifying the chg-assoc command
with the open=no and alw=no parameters, as necessary. For this example, enter this command.
chg-assoc:aname=assoc11:open=no:alw=no
When this command has successfully completed, this message should appear.
rlghncxa03w 06-10-28 09:12:36 GMT EAGLE5 36.0.0
CHG-ASSOC: MASP A - COMPLTD;
6. Deactivate the link to be removed using the dact-slk command, using the output from
obtain the card location and link parameter value of the signaling link to be removed. For this
example, enter these commands.
dact-slk:loc=2207:link=a
When each of these command has successfully completed, this message should appear.
rlghncxa03w 06-10-07 08:41:12 GMT
Deactivate Link message sent to card
7. Verify that the link is out of service - maintenance disabled (OOS-MT-DSBLD) using the
rept-stat-slk command with the card location and link parameter values specified in
6. For this example, enter these commands.
910-6278-001 Revision A, January 2012
SLKTPS LSUSEALM
500 100%
NUMSLKRSTR NUMSLKPROH
1 1
LINK SLC TYPE ANAME
0 IPSG assoc11
procedure to change the required values. After the
has been performed, continue the procedure with
IPSG M2PA and M3UA Configuration Procedures
SLKUSEALM RCONTEXT
80% none
EAGLE5 36.0.0
ASNOTIF
yes
Step 4
Step 5.
Step 6.
Step 1
to
Step
