Tekelec IP7 Secure Gateway Administration Manual page 746

Database Administration Manual - IP7 Secure
Gateway
IP Appl Sock/Assoc table is (4 of 4000) 1% full
Assoc Buffer Space Used (200 KB of 800 KB) on LOC = 1203
An IPSG card can contain a maximum of 32 IPSG M2PA or M3UA associations. If 32 associations
are displayed in the rtrv-assoc output, the new IPSG M3UA association cannot be added to
this card. Choose another IPSG card and repeat this procedure from
If less than 32 associations are shown in the rtrv-assoc output, continue the procedure with
Step 6.
4. Display the IP links in the database by entering the rtrv-ip-lnk command. The following is an
example of the possible output.
rlghncxa03w 08-12-28 21:14:37 GMT EAGLE5 40.0.0
LOC PORT IPADDR
1201 A 192.1.1.10
1201 B --------------- --------------- HALF
1203 A 192.1.1.12
1203 B --------------- --------------- HALF
1205 A 192.1.1.14
1205 B --------------- --------------- HALF
2101 A 192.1.1.20
2101 B --------------- --------------- HALF
2103 A 192.1.1.22
2103 B --------------- --------------- HALF
2105 A 192.1.1.24
2105 B --------------- --------------- HALF
2205 A 192.1.1.30
2205 B --------------- --------------- HALF
2207 A 192.1.1.32
2207 B --------------- --------------- HALF
2213 A 192.1.1.50
2213 B --------------- --------------- HALF
2301 A 192.1.1.52
2301 B --------------- --------------- HALF
IP-LNK table (20 of 2048) 1% full.
If the required IP link is not in the database, add the IP link using the
procedure.
5. Verify that the local host name to be assigned to the association is in the database by using the
rtrv-ip-host:display=all command. The following is an example of the possible output.
rlghncxa03w 08-12-28 21:15:37 GMT EAGLE5 40.0.0
LOCAL IPADDR
192.1.1.10
192.1.1.12
192.1.1.14
192.1.1.20
192.1.1.22
192.1.1.24
192.1.1.30
192.1.1.32
192.1.1.50
192.1.1.52
REMOTE IPADDR
150.1.1.5
910-6278-001 Revision A, January 2012
SUBMASK
255.255.255.128 HALF
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
LOCAL HOST
IPNODE1-1201
IPNODE1-1203
IPNODE1-1205
IPNODE2-1201
IPNODE2-1203
IPNODE2-1205
KC-HLR1
KC-HLR2
DN-MSC1
DN-MSC2
REMOTE HOST
NCDEPTECONOMIC_DEVELOPMENT. SOUTHEASTERN_COORIDOR_ASHVL. GOV
IPSG M2PA and M3UA Configuration Procedures
DUPLEX SPEED MACTYPE AUTO MCAST
10
10
---- ---
10
FULL 100
10
FULL 100
10
FULL 100
10
FULL 100
10
FULL 100
10
FULL 100
10
FULL 100
10
FULL 100
10
Step 1.
802.3 NO NO
DIX NO NO
DIX YES NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
Configuring an IP Link
746
