Choose another adjacent point code value and repeat the procedure from
Remove all the entries displayed in this step by performing the "Removing a Route Exception
Entry" procedure in the Database Administration Manual - SS7 . After the entries have been
removed, continue the procedure with
If the point code specified in this step is not shown in the DPCA/DPCI/DPCN/ DPCN24 columns
in this step, continue this procedure with
6. Display any entries in the route table whose DPC value is also the adjacent point code of the new
linkset being added in this procedure, or the new adjacent point code of the existing linkset being
changed in this procedure. Enter the rtrv-rte command with the dpc/dpca/dpci/dpcn/dpcn24
parameter. The dpc/dpca/dpci/dpcn/dpcn24 parameter value is the adjacent point code value
that will be specified for the linkset. For this example, enter this command.
rtrv-rte:dpca=010-020-005
This is an example of the possible output.
rlghncxa03w 10-07-10 11:43:04 GMT EAGLE5 42.0.0
DPCA
010-020-005 ---------- --------------
If the adjacent point code of the linkset is not the DPC of a route, the point code entry is displayed
in the rtrv-rte output, but the LSN, RC, and APC columns contain dashes, as shown in the
following output example.
rlghncxa03w 10-07-10 11:43:04 GMT EAGLE5 42.0.0
DPCA
010-020-005 ---------- --------------
If the point code specified in this step is shown in the DPCA/DPCI/DPCN/ DPCN24 columns in this
step, the point code value cannot be used as an adjacent point code unless one of two actions are
taken:
Choose another adjacent point code value and repeat and repeat the procedure from
Remove all the entries displayed in this step by performing the "Removing a Route" procedure
in the Database Administration Manual - SS7 . After the entries have been removed, continue the
procedure with
If the point code specified in this step is not shown in the DPCA/DPCI/DPCN/ DPCN24 columns
in this step, continue this procedure with
7. Display the total provisioned system TPS by entering the rtrv-tps command. This is an example
of the possible output.
rlghncxa03w 10-07-10 16:20:46 GMT
CARD NUM
TYPE CARDS
----- -----
IPGW 17
IPSG 3
IPLIM 2
910-6278-001 Revision A, January 2012
ALIASI ALIASN/N24
ALIASI ALIASN/N24
Step 7 .
NUM RSVD
LINKS TPS
----- -------- --------
16 48000
7 4200
4 8000
IPSG M2PA and M3UA Configuration Procedures
Step 6.
Step 6.
LSN
lsn1
lsn2
RTX:No
LSN
lsn1
lsn2
RTX:No
Step 7.
EAGLE 42.0.0
MAX
TPS
80000
8000
8000
Step 2.
RC APCA
1 003-003-005
2 003-003-004
CLLI=-----------
RC APCA
1 003-003-005
2 003-003-004
CLLI=-----------
Step 2.
