Database Administration Manual - IP7 Secure
Gateway
The enable-ctrl-feat command requires that the database contain a valid serial number for the
EAGLE 5 ISS, and that this serial number is locked. This can be verified with the rtrv-serial-num
command. The EAGLE 5 ISS is shipped with a serial number in the database, but the serial number
is not locked. The serial number can be changed, if necessary, and locked once the EAGLE 5 ISS is
on-site, by using the ent-serial-num command. The ent-serial-num command uses these
parameters.
:serial – The serial number assigned to the EAGLE 5 ISS. The serial number is not case sensitive.
:lock – Specifies whether or not the serial number is locked. This parameter has only one value, yes,
which locks the serial number. Once the serial number is locked, it cannot be changed.
Note: To enter and lock the EAGLE 5 ISS's serial number, the ent-serial-num command must be
entered twice, once to add the correct serial number to the database with the serial parameter, then
again with the serial and the lock=yes parameters to lock the serial number. You should verify
that the serial number in the database is correct before locking the serial number. The serial number
can be found on a label affixed to the control shelf (shelf 1100).
This feature cannot be temporarily enabled (with the temporary feature access key).
Once this feature is enabled with the enable-ctrl-feat command, the feature is also activated.
The chg-ctrl-feat command is not necessary to activate the feature.
This feature cannot be turned off with the chg-ctrl-feat command and the status=off parameter.
Hardware Supported for Signaling Link Quantities Greater than 2000
This hardware is the only hardware that is supported for an EAGLE 5 ISS containing 2001 to 2800
signaling links.
HC-MIM
E5-E1/T1
E5-ATM
E5-SM4G
E5-ENET
E5-based control cards
Single-Slot EDCM or E5-SLAN card for the STPLAN feature
Single-Slot EDCM or E5-STC card for the EAGLE 5 Integrated Monitoring Support feature
To increase the signaling link quantity to more than 2000 signaling links, HIPR or HIPR2 cards must
be installed into card locations 9 and 10 in each shelf in the EAGLE 5 ISS. Enter the
rept-stat-gpl:gpl=hipr command to verify whether or not HIPR cards are installed in the
EAGLE 5 ISS shelves. Enter the rept-stat-gpl:gpl=hipr2 command to verify whether or not
HIPR2 cards are installed in the EAGLE 5 ISS shelves.
1. Display the status of the Large System # Links controlled feature by entering the rtrv-ctrl-feat
command.
The following is an example of the possible output.
rlghncxa03w 06-10-28 21:15:37 GMT EAGLE5 36.0.0
The following features have been permanently enabled:
Feature Name
Command Class Management
LNP Short Message Service 893006601
Intermed GTT Load Sharing 893006901
XGTT Table Expansion
910-6278-001 Revision A, January 2012
Partnum Status
893005801 on
on
on
893006101 on
Reference Information
Quantity
----
----
----
400000
1034
