Database Administration Manual - IP7 Secure
Gateway
Attributes of a M3UA or SUA Association
in the Commands Manual.
Canceling the RTRV-ASSOC Command
Because the rtrv-assoc command used in this procedure can output information for a long period
of time, the rtrv-assoc command can be canceled and the output to the terminal stopped. There
are three ways that the rtrv-assoc command can be canceled.
Press the F9 function key on the keyboard at the terminal where the rtrv-assoc command was
entered.
Enter the canc-cmd without the trm parameter at the terminal where the rtrv-assoc command
was entered.
Enter the canc-cmd:trm=<xx>, where <xx> is the terminal where the rtrv-assoc command
was entered, from another terminal other that the terminal where the rtrv-assoc command was
entered. To enter the canc-cmd:trm=<xx> command, the terminal must allow Security
Administration commands to be entered from it and the user must be allowed to enter Security
Administration commands. The terminal's permissions can be verified with the rtrv-secu-trm
command. The user's permissions can be verified with the rtrv-user or rtrv-secu-user
commands.
For more information about the canc-cmd command, go to the Commands Manual.
1. Display the associations in the database using the rtrv-assoc command.
This is an example of possible output.
rlghncxa03w 06-10-28 09:12:36 GMT EAGLE5 36.0.0
ANAME
swbel32
a2
a3
assoc1
If the association that is being removed in this procedure is an SUA association, continue the
procedure with
If the association that is being removed in this procedure is an M3UA association, continue the
procedure with
2. Enter the rtrv-card command with the location of the card that is hosting the M3UA association
that will be changed in this procedure. For this example, enter this command.
rtrv-card:loc=1201
This is an example of possible output.
rlghncxa03w 08-03-06 15:17:20 EST EAGLE5 38.0.0
CARD TYPE
1201 DCM
If the application assigned to the card is SS7IPGW or IPGWI, shown in the APPL column, continue
the procedure with
If the application assigned to the card is IPSG, perform the
Retransmission Control
910-6278-001 Revision A, January 2012
procedure, or in the and chg-assoc command description
CARD IPLNK
LOC PORT LINK ADAPTER LPORT RPORT OPEN ALW
1201 A A
1305 A A
1307 A A
1201 A A
Step 3.
Step 2.
APPL LSET NAME
SS7IPGW lsn1
Step 3.
procedure.
IETF M3UA and SUA Configuration Procedures
M3UA 1030 2345
SUA 1030 2345
SUA 1030 2346
M3UA 2000 1030
LINK SLC LSET NAME
A 0
Configuring an IPSG Association for SCTP
YES YES
YES YES
YES YES
YES YES
LINK SLC
